Aspire Coil Compatibility Guide: Which Coil Fits Your Kit?

Aspire makes some of the most reliable coil-based devices in the UK market, but their coil range can be confusing. BVC, Nautilus mesh, BP coils, Gotek pods, Cleito - each coil family fits a specific set of devices and delivers a different vaping experience. Ordering the wrong coils is a frustratingly common mistake, so this guide aims to clear things up once and for all.

Below you will find a breakdown of every current Aspire coil family, which devices they are compatible with, the resistance options available, and the wattage ranges that produce the best results. For a broader look at how coils work in general, start with our complete vape pods and coils guide.

Aspire Coil Families Overview

Aspire has built its reputation on devices that suit mouth-to-lung (MTL) vapers, particularly people switching from cigarettes. Rather than using one universal coil format, Aspire produces several distinct coil families, each engineered for a specific product line.

The coil families you will encounter most often at UK Vape World are:

• BVC (Bottom Vertical Coil) - for the original Nautilus series including Nautilus 2 and Nautilus 2S
• Nautilus mesh coils - for the Nautilus Prime and Nautilus Prime X
• BP coils - for BP80, BP60, and related pod-mod hybrid kits
• Gotek replacement pods - sealed pod units with built-in coils for the Gotek and Gotek X
• Cleito coils - for the Cleito sub-ohm tank (now older but still widely used)

If you are not sure which coil family your device needs, check the label on your existing coil packaging or the product page for your specific device. In most cases, trying to fit the wrong coil into your tank simply will not work physically, but it is always better to check before ordering to avoid delays.

BVC Coils: The Classic MTL Option

The Bottom Vertical Coil design, known as BVC, is one of the most iconic coil formats in UK vaping history. The coil sits vertically at the base of the tank, drawing e-liquid upward through wicking ports. Because the coil is positioned below the e-liquid level, it stays well saturated, which reduces the risk of dry hits considerably.

BVC coils are threaded and screw into the base of the tank. The main resistance options are:

• 1.8 ohm - low wattage (3 to 6W), produces a very tight, cigarette-like draw with minimal vapour. Ideal for nic salts at 20mg or high-PG freebase liquids.
• 1.6 ohm - runs at 6 to 9W, slightly warmer with a fraction more vapour, still very MTL in character
• 0.7 ohm mesh - runs at 13 to 18W, the warmest BVC option with noticeably more flavour and vapour, though still an MTL draw

BVC coils are compatible with the Nautilus, Nautilus Mini, Nautilus 2, and Nautilus 2S. They are not compatible with the Nautilus Prime or Nautilus Prime X. If you have an older Nautilus tank and want to understand when it is time to swap a coil out, our guide to when to change your vape coil covers all the signs.

Nautilus Mesh Coils

Introduced with the Nautilus Prime, Nautilus mesh coils use a flat mesh heating element rather than the traditional wire-wound coil of the BVC range. Mesh provides a larger contact surface area and more even heat distribution, which translates into more consistent flavour and a faster response when you fire the device.

Nautilus mesh coils are available in two main options:

• 1.0 ohm mesh - the most popular choice for MTL vapers on the Prime series, best run at 14 to 18W. Delivers clean, accurate flavour with a satisfying throat hit at 10 to 20mg nic salt.
• 0.7 ohm mesh - runs at 20 to 25W, provides a warmer draw that sits between a tight MTL and a restricted direct-to-lung style

These coils fit the Nautilus Prime and Nautilus Prime X. If you have been wondering whether to prime coils before use, the answer is always yes - our full guide to priming vape coils explains the process step by step.

BP Coils for Pod-Mod Kits

The BP coil range was developed for Aspire's newer pod-mod hybrid devices, primarily the BP80 and BP60. These coils press into the base of the pod cartridge and can be swapped individually without discarding the pod itself, which makes them more economical over time than fully sealed pod systems.

BP coil options include:

• BP 1.0 ohm - MTL coil suited to nic salts, best run at 12 to 15W, produces a tight, flavour-focused draw
• BP 0.3 ohm mesh - versatile option sitting between MTL and DTL, best at 35 to 55W, suits freebase nicotine at 3 to 6mg
• BP 0.2 ohm mesh - full sub-ohm coil for direct-to-lung use, best at 50 to 80W, produces dense vapour clouds

BP coils are only compatible with the BP-series devices. They will not fit any Nautilus, Gotek, or Cleito product.

Gotek and Gotek X Pods

The Aspire Gotek and Gotek X are compact pod kits designed specifically for new vapers and those transitioning from cigarettes. Both devices are stocked by UK Vape World and are popular choices for beginners due to their simplicity and draw-activated firing - no buttons required.

Rather than a separate coil that screws or presses into a tank, the Gotek uses sealed replacement pods that have the coil built directly into the pod body. When the coil degrades, you replace the entire pod unit. This is slightly less economical than replacing coil heads alone, but it is far simpler and requires no priming routine.

Gotek X replacement pods are available in:

• 1.2 ohm - suited to nicotine salts at 10 to 20mg, provides a tight MTL draw close to a cigarette
• 0.8 ohm mesh - slightly airier draw with more flavour intensity, works well with nic salts at 10 to 20mg

Gotek pods are not interchangeable with any other Aspire coil format. The Gotek and Gotek X also use different pod designs from each other, so make sure you select pods specifically labelled for your model.

Device Compatibility Table

Use the table below as a quick reference when ordering replacement coils. The wattage ranges shown are the manufacturer's recommended operating range for the best balance of flavour, vapour, and coil longevity.

Wattage Tips by Coil Type

Running a coil outside its recommended wattage range is the fastest way to shorten its life. Too low and the coil never fully heats, resulting in a cold, muted draw and possible flooding. Too high and you risk burning the cotton wick, which ruins flavour and means replacing the coil far sooner than necessary.

For BVC coils

Start at the lower end of the recommended range and work up in 1W increments until you find the flavour level you prefer. Most vapers using the 1.8 ohm BVC for a cigarette-like experience are happy at around 4 to 5W. The 0.7 ohm mesh BVC performs best around 15 to 16W.

For Nautilus mesh coils

The 1.0 ohm mesh coil performs very well at 16W as a starting point. If the draw feels too cool, nudge up to 17 or 18W. Avoid exceeding 18W as the coil begins to degrade faster above this level. The 0.7 ohm mesh can handle up to 25W but most vapers report best flavour at around 22W.

For BP coils

The 1.0 ohm BP coil suits low-wattage pod use at 12 to 15W. The 0.3 ohm mesh works well at 40W as a starting point, while the 0.2 ohm is a genuine sub-ohm coil that requires 50W or more to perform correctly. Make sure your BP80 or BP60 device is set to an appropriate mode for the coil resistance in use.

For a full explanation of coil resistance and what different ohm ratings mean for your experience, see our guide to vape coils explained.

Buying Tips

When buying Aspire coils, a few practical points will save you time and money:

• Always buy at least a pack of five - individual coils are rarely sold, and having spares means you are never caught short when a coil burns out unexpectedly
• Check the resistance before you buy - if you vape nic salts and prefer a tight draw, stay at 1.0 ohm or above. Sub-ohm options are for lower-nicotine freebase e-liquids only.
• Match your e-liquid PG/VG ratio to the coil type - high-VG e-liquids (70VG and above) are too thick for most MTL coils and will cause dry hits. Stick to 50/50 or high-PG liquids for BVC and Nautilus mesh coils.
• Genuine coils only - counterfeit Aspire coils do exist. Buy from a reputable UK retailer to ensure the coils are genuine and meet UK safety standards.

If you notice your coil burning through faster than usual, it is worth reviewing our vape maintenance guide to check whether cleaning habits or e-liquid choice may be contributing to the issue.
